S07 - Session O3 - Shading effect of trees reduces CO2 but not CH4 and N2O fluxes in urban lawns

Authors: Tom Kunnemann *, Patrice Cannavo, René Guénon, Vincent Guérin

Soils in urban green spaces (UGS) can store significant quantities of organic carbon (C), particularly in the case of lawns largely represented in cities. Lawns are often contrasted in terms of vegetation cover since they are usually associated with heterogeneously distributed trees. Trees create a local microclimate (shade, rainfall, …), modifying biogeochemical cycles (input of litters, symbiotic fungus, …) and can therefore have an important influence on greenhouse gas (GHG) emissions and consequently on C storage. The objective of this study was to understand how the physicochemical properties of soils and microclimatic (temperature and humidity) effects of trees can influence GHG emissions in urban lawns. Soil atmosphere exchange of CO 2 , CH 4 and N 2 O was measured monthly from March to November 2021, with infrared analyzers (CFLUX-1, PP Systems, USA and a DX4040, Gasmet, FINLAND) in 15 UGS composed of open and treed lawns in Angers city (France). Air temperature and soil moisture content were measured simultaneously with GHG fluxes and soil properties (bulk density, pH, conductivity, C and N content) were quantified. We observed that CO 2 fluxes and soil surface temperature were significantly higher in open lawns compared to treed lawns (1216 and 791 mg CO 2 .m - ².h - ¹ respectively with 2,4°C higher in mean during growing season). Soil moisture did not explain the difference in soil respiration. The strong correlation found between CO 2 flux and temperature whatever the soil type, clearly indicates that soil respiration was driven by temperature. However, during this experiment, water availability was not a limiting factor and could change the latter relationship. CH 4 and N 2 O fluxes showed no significant difference between treed and open lawns. These results highlight that treed lawn systems presented less C loss as CO 2 compared to open lawns and could therefore enhance the C sink capacity of urban lawns but night efflux need also to be quantified. Normal 0 21 false false false FR X-NONE X-NONE DefSemiHidden="false" DefQFormat="false" DefPriority="99" LatentStyleCount="375"> UnhideWhenUsed="true" QFormat="true" Name="heading 2"/> UnhideWhenUsed="true" QFormat="true" Name="heading 3"/> UnhideWhenUsed="true" QFormat="true" Name="heading 4"/> UnhideWhenUsed="true" QFormat="true" Name="heading 5"/> UnhideWhenUsed="true" QFormat="true" Name="heading 6"/> UnhideWhenUsed="true" QFormat="true" Name="heading 7"/> UnhideWhenUsed="true" QFormat="true" Name="heading 8"/> UnhideWhenUsed="true" QFormat="true" Name="heading 9"/> Name="index 1"/> Name="index 2"/> Name="index 3"/> Name="index 4"/> Name="index 5"/> Name="index 6"/> Name="index 7"/> Name="index 8"/> Name="index 9"/> UnhideWhenUsed="true" Name="toc 1"/> UnhideWhenUsed="true" Name="toc 2"/> UnhideWhenUsed="true" Name="toc 3"/> UnhideWhenUsed="true" Name="toc 4"/> UnhideWhenUsed="true" Name="toc 5"/> UnhideWhenUsed="true" Name="toc 6"/> UnhideWhenUsed="true" Name="toc 7"/> UnhideWhenUsed="true" Name="toc 8"/> UnhideWhenUsed="true" Name="toc 9"/> Name="Normal Indent"/> Name="footnote text"/> Name="annotation text"/> Name="header"/> Name="footer"/> Name="index heading"/> UnhideWhenUsed="true" QFormat="true" Name="caption"/> Name="table of figures"/> Name="envelope address"/> Name="envelope return"/> Name="footnote reference"/> Name="annotation reference"/> Name="line number"/> Name="page number"/> Name="endnote reference"/> Name="endnote text"/> Name="table of authorities"/> Name="macro"/> Name="toa heading"/> Name="List"/> Name="List Bullet"/> Name="List Number"/> Name="List 2"/> Name="List 3"/> Name="List 4"/> Name="List 5"/> Name="List Bullet 2"/> Name="List Bullet 3"/> Name="List Bullet 4"/> Name="List Bullet 5"/> Name="List Number 2"/> Name="List Number 3"/> Name="List Number 4"/> Name="List Number 5"/> Name="Closing"/> Name="Signature"/> UnhideWhenUsed="true" Name="Default Paragraph Font"/> Name="Body Text"/> Name="Body Text Indent"/> Name="List Continue"/> Name="List Continue 2"/> Name="List Continue 3"/> Name="List Continue 4"/> Name="List Continue 5"/> Name="Message Header"/> Name="Salutation"/> Name="Date"/> Name="Body Text First Indent"/> Name="Body Text First Indent 2"/> Name="Note Heading"/> Name="Body Text 2"/> Name="Body Text 3"/> Name="Body Text Indent 2"/> Name="Body Text Indent 3"/> Name="Block Text"/> Name="Hyperlink"/> Name="FollowedHyperlink"/> Name="Document Map"/> Name="Plain Text"/> Name="E-mail Signature"/> Name="HTML Top of Form"/> Name="HTML Bottom of Form"/> Name="Normal (Web)"/> Name="HTML Acronym"/> Name="HTML Address"/> Name="HTML Cite"/> Name="HTML Code"/> Name="HTML Definition"/> Name="HTML Keyboard"/> Name="HTML Preformatted"/> Name="HTML Sample"/> Name="HTML Typewriter"/> Name="HTML Variable"/> Name="Normal Table"/> Name="annotation subject"/> Name="No List"/> Name="Outline List 1"/> Name="Outline List 2"/> Name="Outline List 3"/> Name="Table Simple 1"/> Name="Table Simple 2"/> Name="Table Simple 3"/> Name="Table Classic 1"/> Name="Table Classic 2"/> Name="Table Classic 3"/> Name="Table Classic 4"/> Name="Table Colorful 1"/> Name="Table Colorful 2"/> Name="Table Colorful 3"/> Name="Table Columns 1"/> Name="Table Columns 2"/> Name="Table Columns 3"/> Name="Table Columns 4"/> Name="Table Columns 5"/> Name="Table Grid 1"/> Name="Table Grid 2"/> Name="Table Grid 3"/> Name="Table Grid 4"/> Name="Table Grid 5"/> Name="Table Grid 6"/> Name="Table Grid 7"/> Name="Table Grid 8"/> Name="Table List 1"/> Name="Table List 2"/> Name="Table List 3"/> Name="Table List 4"/> Name="Table List 5"/> Name="Table List 6"/> Name="Table List 7"/> Name="Table List 8"/> Name="Table 3D effects 1"/> Name="Table 3D effects 2"/> Name="Table 3D effects 3"/> Name="Table Contemporary"/> Name="Table Elegant"/> Name="Table Professional"/> Name="Table Subtle 1"/> Name="Table Subtle 2"/> Name="Table Web 1"/> Name="Table Web 2"/> Name="Table Web 3"/> Name="Balloon Text"/> Name="Table Theme"/> Name="List Paragraph"/> Name="Intense Quote"/> Name="Subtle Emphasis"/> Name="Intense Emphasis"/> Name="Subtle Reference"/> Name="Intense Reference"/> UnhideWhenUsed="true" Name="Bibliography"/> UnhideWhenUsed="true" QFormat="true" Name="TOC Heading"/> Name="Grid Table 1 Light Accent 1"/> Name="Grid Table 6 Colorful Accent 1"/> Name="Grid Table 7 Colorful Accent 1"/> Name="Grid Table 1 Light Accent 2"/> Name="Grid Table 6 Colorful Accent 2"/> Name="Grid Table 7 Colorful Accent 2"/> Name="Grid Table 1 Light Accent 3"/> Name="Grid Table 6 Colorful Accent 3"/> Name="Grid Table 7 Colorful Accent 3"/> Name="Grid Table 1 Light Accent 4"/> Name="Grid Table 6 Colorful Accent 4"/> Name="Grid Table 7 Colorful Accent 4"/> Name="Grid Table 1 Light Accent 5"/> Name="Grid Table 6 Colorful Accent 5"/> Name="Grid Table 7 Colorful Accent 5"/> Name="Grid Table 1 Light Accent 6"/> Name="Grid Table 6 Colorful Accent 6"/> Name="Grid Table 7 Colorful Accent 6"/> Name="List Table 1 Light Accent 1"/> Name="List Table 6 Colorful Accent 1"/> Name="List Table 7 Colorful Accent 1"/> Name="List Table 1 Light Accent 2"/> Name="List Table 6 Colorful Accent 2"/> Name="List Table 7 Colorful Accent 2"/> Name="List Table 1 Light Accent 3"/> Name="List Table 6 Colorful Accent 3"/> Name="List Table 7 Colorful Accent 3"/> Name="List Table 1 Light Accent 4"/> Name="List Table 6 Colorful Accent 4"/> Name="List Table 7 Colorful Accent 4"/> Name="List Table 1 Light Accent 5"/> Name="List Table 6 Colorful Accent 5"/> Name="List Table 7 Colorful Accent 5"/> Name="List Table 1 Light Accent 6"/> Name="List Table 6 Colorful Accent 6"/> Name="List Table 7 Colorful Accent 6"/> Name="Mention"/> Name="Smart Hyperlink"/> Name="Hashtag"/> Name="Unresolved Mention"/> /* Style Definitions */ table.MsoNormalTable {mso-style-name:"Tableau Normal"; mso-tstyle-rowband-size:0; mso-tstyle-colband-size:0; mso-style-noshow:yes; mso-style-priority:99; mso-style-parent:""; mso-padding-alt:0cm 5.4pt 0cm 5.4pt; mso-para-margin-top:0cm; mso-para-margin-right:0cm; mso-para-margin-bottom:8.0pt; mso-para-margin-left:0cm; line-height:107%; mso-pagination:widow-orphan; font-size:11.0pt; font-family:"Calibri",sans-serif; mso-ascii-font-family:Calibri; mso-ascii-theme-font:minor-latin; mso-hansi-font-family:Calibri; mso-hansi-theme-font:minor-latin; mso-bidi-font-family:"Times New Roman"; mso-bidi-theme-font:minor-bidi; mso-fareast-language:EN-US;} Normal 0 21 false false false FR X-NONE X-NONE DefSemiHidden="false" DefQFormat="false" DefPriority="99" LatentStyleCount="375"> UnhideWhenUsed="true" QFormat="true" Name="heading 2"/> UnhideWhenUsed="true" QFormat="true" Name="heading 3"/> UnhideWhenUsed="true" QFormat="true" Name="heading 4"/> UnhideWhenUsed="true" QFormat="true" Name="heading 5"/> UnhideWhenUsed="true" QFormat="true" Name="heading 6"/> UnhideWhenUsed="true" QFormat="true" Name="heading 7"/> UnhideWhenUsed="true" QFormat="true" Name="heading 8"/> UnhideWhenUsed="true" QFormat="true" Name="heading 9"/> Name="index 1"/> Name="index 2"/> Name="index 3"/> Name="index 4"/> Name="index 5"/> Name="index 6"/> Name="index 7"/> Name="index 8"/> Name="index 9"/> UnhideWhenUsed="true" Name="toc 1"/> UnhideWhenUsed="true" Name="toc 2"/> UnhideWhenUsed="true" Name="toc 3"/> UnhideWhenUsed="true" Name="toc 4"/> UnhideWhenUsed="true" Name="toc 5"/> UnhideWhenUsed="true" Name="toc 6"/> UnhideWhenUsed="true" Name="toc 7"/> UnhideWhenUsed="true" Name="toc 8"/> UnhideWhenUsed="true" Name="toc 9"/> Name="Normal Indent"/> Name="footnote text"/> Name="annotation text"/> Name="header"/> Name="footer"/> Name="index heading"/> UnhideWhenUsed="true" QFormat="true" Name="caption"/> Name="table of figures"/> Name="envelope address"/> Name="envelope return"/> Name="footnote reference"/> Name="annotation reference"/> Name="line number"/> Name="page number"/> Name="endnote reference"/> Name="endnote text"/> Name="table of authorities"/> Name="macro"/> Name="toa heading"/> Name="List"/> Name="List Bullet"/> Name="List Number"/> Name="List 2"/> Name="List 3"/> Name="List 4"/> Name="List 5"/> Name="List Bullet 2"/> Name="List Bullet 3"/> Name="List Bullet 4"/> Name="List Bullet 5"/> Name="List Number 2"/> Name="List Number 3"/> Name="List Number 4"/> Name="List Number 5"/> Name="Closing"/> Name="Signature"/> UnhideWhenUsed="true" Name="Default Paragraph Font"/> Name="Body Text"/> Name="Body Text Indent"/> Name="List Continue"/> Name="List Continue 2"/> Name="List Continue 3"/> Name="List Continue 4"/> Name="List Continue 5"/> Name="Message Header"/> Name="Salutation"/> Name="Date"/> Name="Body Text First Indent"/> Name="Body Text First Indent 2"/> Name="Note Heading"/> Name="Body Text 2"/> Name="Body Text 3"/> Name="Body Text Indent 2"/> Name="Body Text Indent 3"/> Name="Block Text"/> Name="Hyperlink"/> Name="FollowedHyperlink"/> Name="Document Map"/> Name="Plain Text"/> Name="E-mail Signature"/> Name="HTML Top of Form"/> Name="HTML Bottom of Form"/> Name="Normal (Web)"/> Name="HTML Acronym"/> Name="HTML Address"/> Name="HTML Cite"/> Name="HTML Code"/> Name="HTML Definition"/> Name="HTML Keyboard"/> Name="HTML Preformatted"/> Name="HTML Sample"/> Name="HTML Typewriter"/> Name="HTML Variable"/> Name="Normal Table"/> Name="annotation subject"/> Name="No List"/> Name="Outline List 1"/> Name="Outline List 2"/> Name="Outline List 3"/> Name="Table Simple 1"/> Name="Table Simple 2"/> Name="Table Simple 3"/> Name="Table Classic 1"/> Name="Table Classic 2"/> Name="Table Classic 3"/> Name="Table Classic 4"/> Name="Table Colorful 1"/> Name="Table Colorful 2"/> Name="Table Colorful 3"/> Name="Table Columns 1"/> Name="Table Columns 2"/> Name="Table Columns 3"/> Name="Table Columns 4"/> Name="Table Columns 5"/> Name="Table Grid 1"/> Name="Table Grid 2"/> Name="Table Grid 3"/> Name="Table Grid 4"/> Name="Table Grid 5"/> Name="Table Grid 6"/> Name="Table Grid 7"/> Name="Table Grid 8"/> Name="Table List 1"/> Name="Table List 2"/> Name="Table List 3"/> Name="Table List 4"/> Name="Table List 5"/> Name="Table List 6"/> Name="Table List 7"/> Name="Table List 8"/> Name="Table 3D effects 1"/> Name="Table 3D effects 2"/> Name="Table 3D effects 3"/> Name="Table Contemporary"/> Name="Table Elegant"/> Name="Table Professional"/> Name="Table Subtle 1"/> Name="Table Subtle 2"/> Name="Table Web 1"/> Name="Table Web 2"/> Name="Table Web 3"/> Name="Balloon Text"/> Name="Table Theme"/> Name="List Paragraph"/> Name="Intense Quote"/> Name="Subtle Emphasis"/> Name="Intense Emphasis"/> Name="Subtle Reference"/> Name="Intense Reference"/> UnhideWhenUsed="true" Name="Bibliography"/> UnhideWhenUsed="true" QFormat="true" Name="TOC Heading"/> Name="Grid Table 1 Light Accent 1"/> Name="Grid Table 6 Colorful Accent 1"/> Name="Grid Table 7 Colorful Accent 1"/> Name="Grid Table 1 Light Accent 2"/> Name="Grid Table 6 Colorful Accent 2"/> Name="Grid Table 7 Colorful Accent 2"/> Name="Grid Table 1 Light Accent 3"/> Name="Grid Table 6 Colorful Accent 3"/> Name="Grid Table 7 Colorful Accent 3"/> Name="Grid Table 1 Light Accent 4"/> Name="Grid Table 6 Colorful Accent 4"/> Name="Grid Table 7 Colorful Accent 4"/> Name="Grid Table 1 Light Accent 5"/> Name="Grid Table 6 Colorful Accent 5"/> Name="Grid Table 7 Colorful Accent 5"/> Name="Grid Table 1 Light Accent 6"/> Name="Grid Table 6 Colorful Accent 6"/> Name="Grid Table 7 Colorful Accent 6"/> Name="List Table 1 Light Accent 1"/> Name="List Table 6 Colorful Accent 1"/> Name="List Table 7 Colorful Accent 1"/> Name="List Table 1 Light Accent 2"/> Name="List Table 6 Colorful Accent 2"/> Name="List Table 7 Colorful Accent 2"/> Name="List Table 1 Light Accent 3"/> Name="List Table 6 Colorful Accent 3"/> Name="List Table 7 Colorful Accent 3"/> Name="List Table 1 Light Accent 4"/> Name="List Table 6 Colorful Accent 4"/> Name="List Table 7 Colorful Accent 4"/> Name="List Table 1 Light Accent 5"/> Name="List Table 6 Colorful Accent 5"/> Name="List Table 7 Colorful Accent 5"/> Name="List Table 1 Light Accent 6"/> Name="List Table 6 Colorful Accent 6"/> Name="List Table 7 Colorful Accent 6"/> Name="Mention"/> Name="Smart Hyperlink"/> Name="Hashtag"/> Name="Unresolved Mention"/> /* Style Definitions */ table.MsoNormalTable {mso-style-name:"Tableau Normal"; mso-tstyle-rowband-size:0; mso-tstyle-colband-size:0; mso-style-noshow:yes; mso-style-priority:99; mso-style-parent:""; mso-padding-alt:0cm 5.4pt 0cm 5.4pt; mso-para-margin-top:0cm; mso-para-margin-right:0cm; mso-para-margin-bottom:8.0pt; mso-para-margin-left:0cm; line-height:107%; mso-pagination:widow-orphan; font-size:11.0pt; font-family:"Calibri",sans-serif; mso-ascii-font-family:Calibri; mso-ascii-theme-font:minor-latin; mso-hansi-font-family:Calibri; mso-hansi-theme-font:minor-latin; mso-bidi-font-family:"Times New Roman"; mso-bidi-theme-font:minor-bidi; mso-fareast-language:EN-US;}
